基于像素的碰撞检测(移植到cocos2dx 3.x)(基于像素的分类方法)

编辑:rootadmin
感谢原文: 2.x的,我修改了一下,这个版本是Cocos2d-x 3.x可用版本。Pixel Perfect Collision Detection (Using Cocos2d-x 3.x)This post found its way because I couldnt find the answer to one of the questions I asked on StackOverflow ( and thought there would be others like me in search for an answer.Collision detection is an integral part of almost all games. It is used to find when a bullet hits an enemy or when you bump into a wall etc.There are many different requirements when we do collision detection and depending on our game we choose one of the many detection techniques.The default Collision detection mechanism used by games and provided in almost all game engines and frameworks is a “Bounding Box” collision.Simply put, a “Bounding Box” collision detection system the sprites/objects being checked for collision are treated as the smallest rectangle which completely engulfs them. Then these two Boxes are checked if they are colliding with each other.But sometimes this very simple collision detection system is not accurate. Specially when we use sprites with alpha values (mostly png files) or when our objects are rotated by some angles. See the image below: Pixel – Perfect collision detection is a system where we check if the objects concerned are actually colliding rather than just being part of a bounding box which is bigger than their size. WARNING: This system though more accurate is obviously more performance intensive and hence depending on your game requirements choose wisely about which of the different systems you want to use.TIP: This system though written specially for Cocos2d-x framework can be easily understood and implemented for any language/framework you are using.So its time to get our hands dirty,We are going to develop a Singleton Class for collision detection and just plug and play this in any project we are doing.Things used:1. Singleton Class – CollisionDetection2. Opengl Vertex and Fragment Shaders3. CCRenderTexture Class – Cocos2d-xTheory:1. Create a CCRenderTexture which is going to serve as a secondary draw buffer.2. We first do a simple collision detection (Bounding Box) to check if the two sprite’s bounds are colliding3. If step 2 is a success then we are going to draw the two concerned objects in our secondary buffer we created in step 1. (We are going to set its visibility to false, so that even though we draw something, nothing will we visible to the end user)4. Using openGL fragment shaders we are going to draw one of the objects completely RED and the other completely BLUE! 5. Using another of openGL functionality glReadPixels we are going to read the pixels data of all the pixels in the Rectangular area (Intersection area) of the bounding box collision6. We are then going to loop through all the pixel values and check if a single pixel has BOTH the RED and the BLUE pixels. If they have then the objects are actually colliding or else not.Now here is the code for the above steps. I have commented the code for you to understand what is going on. If there are any questions please leave in the comments and I will try and answer to the best of my knowledge

推荐整理分享基于像素的碰撞检测(移植到cocos2dx 3.x)(基于像素的分类方法),希望有所帮助,仅作参考,欢迎阅读内容。

文章相关热门搜索词:基于像素的图像增强方法是一种非线性灰度变换,像素碰撞检测,像素碰撞检测,基于像素的分类方法,基于像素的图像,也可以称为,像素碰撞检测,基于像素的图像,也可以称为,像素碰撞3d,内容如对您有帮助,希望把文章链接给更多的朋友!

CollisionDetection.h

CollisionDetection.cpp

SolidColorShader.fsh基于像素的碰撞检测(移植到cocos2dx 3.x)(基于像素的分类方法)

SolidVertexShader.vsh

For using the Collision Detection Class:

1. Initialize the CCRenderTexture object

2. Call the Singleton function whenever collision detection required
